    SHARK 660 CNC HS 4.0

    Product Code: SHARK 660 CNC HS 4.0

    Shark 660 CNC HS 4.0, automatic double-column bandsaw for 0° cuts on structural, stainless, alloy steels, profiles ,solid parts and profiles with dimensions up to 660x660mm.
    – CNC machine with a new controller: MEP 40.
    It has been specifically designed by MEP for the automation of its range of products.
    – This sawing machine also features a semiautomatic cutting cycle and uses latest generation technologies;
    indeed, Shark 660 CNC HS 4.0 is equipped with a NEW controller with processor RISC 32 bit 200 MHz
    with integrated interface to:
    – Install a GSM card (OPTIONAL) to send an SMS to the programmed number notifying the type of emergency occurred while the machine was operating unattended.
    – Connect to an Ethernet network for the remote assistance service.
    – Get software updates and changes by e-mail, that is transferred to USB port by SD or MMC card and later on the control memory, through the suitable slot on the control console.
    – Choose in the library (that can be extended by the user) the material type, geometry and hardness, the type of band to be used and the control automatically sets: position of the cutting head, feed rate, and the blade rotation speed.
    OTHER FEATURES:
    – 8” touchscreen display operator interface and push buttons for all functions of the sawing machine. It is simple and intuitive, with a self-learning feature it guarantees a reliable use and it controls all cutting parameters in real time.
    – Automatic acquisition of the actual starting point of the cut.
    – CNC machine to store up to 300 cutting programs each with different quantity and length.
    – Structure in sturdy cast iron, to absorb vibrations and give the machine a better cutting stability and longer blade life.
    – Cutting head downfeed movement with 2 brushless motors and with recirculating ballscrews-nut, with hydraulic compensation of the cutting head.
    – The cutting head movement is with linear guides and ball-recirculating pre-charged slides.
    – Hydraulic power pack to supply the feeding vices, cutting vices and carbide pads.
    – Infinitely adjustable cutting speed from 15 to 200 m/min by vector inverter.
    – Bar feeder with recirculating balls, screw/nut and stepper motor (feeding length in one stroke 760 mm or 30” that can be repeated in order to cut any length)
    – Self-aligning feeder vice unit for feeding even strained bars.
    – Rest piece that can no longer be in-feeded automatically by feeder: 70mm.
    – Driving and idler pulley locked by conical clamping ring.
    – Software to control/assess/correct in real time: – cutting force – cutting torque and band tensioning against the programmed values.
    – Control panel, with and adjustable frame, assembled on a rotating arm.
    – Adjustable blade guide blocks. This system, that guides the blade, is a combination of pre-charged rollers and carbide inserts.
    – Idler pulley movement from the keyboard to replace the band easily.
    – Automatic adjustment of the front blade-guide head according to the dimensions of the bars to be cut.
    – Blade deviation device.
    – Laser projector to position the bar accurately to carry out non-standard or facing cuts.
    – Band rotation control with stop in real time in case of blade jammed.
    – Electro-mechanical servo-system for the blade dynamic tensioning.
    – Coolant tank incorporated in the base.
    – Blade cooling with lubricating oil by means of two coolant pumps. Each pump has a 120l/min flow rate.
    – Wash gun to clean the machine.
    – Powered blade brush.
    – Chip conveyor.
    – Sound and flashing indicator.
    – Bimetallic band for profiles and solid pieces.
    – Service keys and instructions manual, for maintenance and spare parts list.
    FEATURED SPECIFICATIONS:

    Package: 1 Pairs
