    Aluminium Profile Processing Center

    Product Code: AIM 4310

    Product Information

    AIM 4310 is 3-axis CNC controlled machining center which is designed for working of all kinds of aluminum & PVC profiles, light alloys in general and thin walled steel profiles.

    By means of additional aggregate tool, various profiles can be machined with 4-axis movement. The machine can be used in tandem mode, a work method that allows machine stop times to be reduced to a minimum as it allows workpiece change time (loading/unloading) to be run“while the machine is operating.

    The machine has automatic clamp positioning feature and equipped with magazine unit holding 8 tool-units with the possibility of placing 2 aggregate tools and 1 milling saw to perform machining on the 5 sides of the pieces.

    • Designed for all kinds of drilling, grooving, notching, taping etc. on aluminum profiles
    • Uninterrupted machining property by means of the tandem mode to reduce the workpiece change time
    • B&R automation system enabling CNC movement on 3 axis
    • 8 tool magazine unit, 6 for cutter bits, 1 for aggregates and 1 for saw blade
    • Solid steel construction of the body and dynamic performance gantry
    • Special sound insulation cabinet around the machining center
    • PLC controlled spray tool cooling system with 3 pcs of outlets
    • 4 x automatic clamps used for grabbing the work piece
    • 2 x pneumatic rests used for resetting the work piece in X direction
    • 15’’ color touch screen
    • Fast programming using 7 preset macros
    • Program import via USB flash memory stick
    • Technical support via remote connection capability
    • Standard ISO ‘G’ code programming language
    • Central lubrication system
    • Multi-language support
    • Operator safety barrier
    • LED lighting in the cabinet


    • Machine with 7 m of length
    • Automatic clamp positioning via Advance Alpha CAM software
    • Rapid programming with Standard Alpha CAM software
    • Tapping chuck (up to M10)
    • Automatic tool length measurement device
    • Barcode-Scanner
    • Chip removal conveyor belt
    • Additional clamps
    • Aggregate tools
    • Cutter tools, milling saw, tool holder and collets
    • Additional magazine unit with 6 tool capacity

    Package: 1 Pairs
