    Max force 300 N Stroke 300mm

    Product Code: VEGA


    Die-cast aluminium casing with a very small section (45 x 32 mm) that can be easily built-in into the frame of curtain walls.

    300 mm stroke chain in double stainless steel links. Chain exit in central position. The manual closing position regulation is not required: the stop in closing position is regulated by an electronic limit switch control.
    Electronic stop in the intermediate positions in case of overload.
    The VEGA RF version has an integrated radio receiver and it is supplied with radio remote control; the transmitter controls simultaneously more actuators within its field of action; available on request actuators and remote controls with different radio codes.
    Available versions on request:
    UR and UL versions
    F-SIGNAL Vdc is a special version with opening and closing feedback signal (free potential, maintained contact)
    VEGA DC version with protection class IP32
    BMSline version with programmable features (stroke, speed, force,…) and different scenarios selectable with a connection to a computer and dedicated software – see “BMSline” section

    Package: 1 Pairs
