GENERAL FEATURES

• All parameters such as melting and welding time, welding pressure are set
independently
• User friendly with the features of cleaning the plates and replacing teflon very
easily and quickly
• Thanks to the profile support arms, long profiles can be easily welded
• Practical adjustment of standard (2.0 mm) or seamless (0.2 mm) welding options
manually
• Profile support arms are supplied as standard in both directions
• Adjusting the heat between 0 – 300°C by means of the electronic thermocouple
• Saving of time thanks to the practical mold change feature
• Automatically start and finish the welding cycle
• Enable the welding of all angles between 30° – 180° infinitely adjustable
• Clamping the profiles separately via foot pedal
• Maximum H: 180 mm welding capability

STANDARD ACCESSORIES

• Electrical foot pedal
• Profile support arms

OPTIONAL ACCESSORIES

• Special welding molds
